Solvis Ben

SolvisBen Solo

SolvisBen Solo mit WWS 30, HKS 4,0 230L

Heating buffer layer storage tank with boiler flange for burner retrofitting for

energy-efficient heat management. With very efficient fresh water preparation. Stable temperature stratification through patented loading elance technology.

Strong insulation through innovative, multifunctional thermal insulation cladding. Well suited for connecting other heat sources such as an example thermal solar  system or an electric immersion heater for the use of PV overage.

Consisting of:

• Storage tank made of S235JR with built-in components, primed on the outside,  raw inside

• Blind flange for retrofitting the boiler

• SolvisControl 3 system controller with touchscreen displays

• Hot water station with volume flow and temperature sensors

• All parameters and messages relevant to the operation can be in the central controller can be read out

• Integrated data logging for system monitoring and evaluation

• Self-regulating, maintenance-free solar stratified charger

• Loading lance for the return of the heating circuits

• Multifunctional, multi-part and removable thermal insulation cladding

• Socket for the optional installation of an electric heating element

• adjustable container handle to compensate for uneven floors

• Room control element

• Storage sensor wiring harness

• Heating safety valve

• Connection line and connection group with cap valve, KFE cock and manometer for a heating  expansion vessel

• Documentation (operating instructions, commissioning, maintenance log)

Note:

Including

• Hot water station

• one Heating mixing station
